Brand Name

KEYU

Model Number

K-pickup

Number of Seats

2

Curb Weight

685kg

Steering System

Gear chain

Tire Size

165-70R12 Pneumatic tyres

Size

3550*1370*1550mm

Carriage size

1640*1280*300mm

Max speed

50km/h

Min steering radius

≤4.5m

Max climbing ability(full)

20%

Working Range

80-100 Km

Motor

3KW、4KW or 5KW AC motor is optional

Braking Method

Front disc and rear drum

Battery

60V or 72V lead acid battery or lithium battery

Wheel base(mm)

2315

Wheel tread(mm)

1195/1190

Min Ground Clearance(mm)

≥150

Loading Capacity(kg)

500

Body Structure

Intelligent loading body

Charger

Build-in smart car charger

Charging time(h)

5-10h

Controller

Imported in-power controller

Driven Method

RR
